9100 Series Standard Body
Developed for the professional off-road racer, the BILSTEIN 9100 Series is truly state-of-the-art. The Standard Body is an extreme duty take-apart damper designed for off-road racing.
Features and Benefits:
- Monotube gas pressure construction
- 2.65 or 2 (OD) Body
- Hose length andFittings Options: Straight, 90 degree, 45 degree
- Valving can be adjusted internally for rebound and compression.
- Completely owner rebuildable.
9100 Series Coilover
Developed for the professional off-road racer, the BILSTEIN 9100 Series is truly state-of-the-art. The Coilover offers the same damping features as the standard body shock with the ability to mount an external coil spring for load carrying capability.
Features and Benefits:
- Monotube gas pressure construction
- Designed to combine the function of damper and spring
- 2.65 or 2 (OD) Body
- Coil Spring Hardware: 3 or 3-5/8 (ID)
- Hose length and Fittings Options: Straight, 90 degree, 45 degree
- Valving can be adjusted internally for rebound and compression.
- Completely owner rebuildable
Special Notes:
- BILSTEIN does not manufacture or sell coil springs for off-road use. However, most BILSTEIN off-road retailers sell springs. They can also offer advice on spring rates.
- It is not recommended to use a coilover in conjunction with an auxiliary spring source, such as Leaf Springs or Torsion Bars.
9100 Series External Bypass
Off-Road Racing Performance
BILSTEIN 9100 Series External Bypass Shocks were developed for the professional racer, and are truly state-of-the-art. It is an extreme duty, take-apart monotube damper designed specifically for off-road racing.
Features and Benefits:
- Widest range of tuning combinations within the industry
- Available in 2.0 or 2.65 body
- Completely owner tunable and rebuildable
- Available in piggyback and various hose lengths
- Bypass tubes allow for position sensitive damping adjustability custom bypass layouts available
Special Notes:
- External Bypass dampers require an external spring source such as a coilover, leaf spring, torsion bar, or auxiliary coil. These dampers will not support a vehicle.
9100 Series Rock Crawler
Designed for the rapidly growing rock crawler market the 9100 Series Rock Crawler features BILSTEINs industry leading technology and the experience gained in decades of off road competition.
Features and Benefits:
- Monotube gas pressure construction
- Nickel plated 2 diameter threaded body
- 2.5 x 12 reservoir with -8 Aeroquip Match Mate hose
- Hard anodized screw top and Aurora spherical bearings
- Valved specifically for rock crawling
- Optional coilover setup with dual rate spring
- Available in 12, 14 and 17 travel
- Completely owner rebuildable
9100 Series Bump Stop
The BILSTEIN Bump Stop improves suspension performance with more up-travel impact control and durability for off-road racing vehicles and prerunners.
Features and Benefits:
- Monotube gas pressure construction
- 2, 3, and 4 travel available for expanded range of fitments
- Seamless steel & electroless nickel finished design
- Nitrogen adjustable spring rate capability
- Delron contact pad for quiet performance
Application:
- UNIVERSAL NON APPLICATION SPECIFIC
