Real Street RS1600 Pistons 1600HP DLC Pins for 2JZ-GTE 90mm Stroker 86.5mm +0.5mm Bore -11.31 9.3:1

click to zoom in

Real Street RS1600 Pistons 1600HP DLC Pins for 2JZ-GTE 90mm Stroker 86.5mm +0.5mm Bore -11.31 9.3:1

Description

Real Street RS1600 Pistons 1600HP DLC Pins 2JZ-GTE 90mm Stroker 86.5mm +0.5mm Bore -11.31 9.3:1

Additional Applications:

Supra MKIV Twin-Turbo 93-98 JZA80
Supra MKIV Non-Turbo 93-98 JZA80
SC300/Soarer 92-00 Z30
IS300 01-05 XE10
GS300/Aristo 91-97 S140
GS300/Aristo 98-05 S160

CP Pistons

Real Street RS1600 Pistons 1600HP DLC Pins for 2JZ-GTE 90mm Stroker 86.5mm +0.5mm Bore -11.31 9.3:1

Part Number:

RS02-16KD8650LM

MSRP: $2,506.55

Your Price: $2,237.99

(You save $268.56 )

Deal ends in:

Description

Description

Real Street RS1600 Pistons 1600HP DLC Pins 2JZ-GTE 90mm Stroker 86.5mm +0.5mm Bore -11.31 9.3:1

Additional Applications:

Supra MKIV Twin-Turbo 93-98 JZA80
Supra MKIV Non-Turbo 93-98 JZA80
SC300/Soarer 92-00 Z30
IS300 01-05 XE10
GS300/Aristo 91-97 S140
GS300/Aristo 98-05 S160

Applicable Engines:

2JZ-GE, 2JZ-GE VVTi, 2JZ-GTE, 2JZ-GTE VVTi

Bore:

86.5mm

Primary Application:

Toyota Supra MKIV

Rod Length:

5.590" / 142mm

Rod Length Oversize:

Standard Length

Bore Oversize:

0.020" / 0.5mm

Stroke:

90mm (3.2L Stroker)

Compression Ratio:

9.3:1

Pin Size:

0.866" / 22mm

Included Ring Set:

CPT-3406PVD

Included Pin:

I866-2500-25CP3C

Head cc:

45 cc

Dome cc:

-11.31

Compression Height:

1.255" / 31.88mm

Piston Coating:

Skirt Coating

Skirt Type:

Full Round

Piston Material:

2618

Wrist Pin Wall Thickness:

0.250"

Wrist Pin Dimensions:

.866" x 2.500" x.250"

Pin Material:

300M DLC

Notes:

The Compression Ratio is 9.548:1

Gasket Thickness:

0.051" / 1.3mm
