CP Pistons

Real Street RS2000 Pistons 2000HP for 2JZ-GTE 90mm Stroker 144mm Rod 86.5mm +0.5mm Bore -14.16cc 8.9:1

click to zoom in

Real Street RS2000 Pistons 2000HP for 2JZ-GTE 90mm Stroker 144mm Rod 86.5mm +0.5mm Bore -14.16cc 8.9:1

Description

Real Street RS2000 Pistons 2000HP 2JZ-GTE 90mm Stroker 144mm Rod 86.5mm +0.5mm Bore -14.16cc 8.9:1

Additional Applications:

Supra MKIV Twin-Turbo 93-98 JZA80
Supra MKIV Non-Turbo 93-98 JZA80
SC300/Soarer 92-00 Z30
IS300 01-05 XE10
GS300/Aristo 91-97 S140
GS300/Aristo 98-05 S160

CP Pistons

Real Street RS2000 Pistons 2000HP for 2JZ-GTE 90mm Stroker 144mm Rod 86.5mm +0.5mm Bore -14.16cc 8.9:1

Part Number:

RS02-20KD8650LS

MSRP: $3,304.44

Your Price: $2,950.39

(You save $354.05 )

Deal ends in:

Description

Description

Real Street RS2000 Pistons 2000HP 2JZ-GTE 90mm Stroker 144mm Rod 86.5mm +0.5mm Bore -14.16cc 8.9:1

Additional Applications:

Supra MKIV Twin-Turbo 93-98 JZA80
Supra MKIV Non-Turbo 93-98 JZA80
SC300/Soarer 92-00 Z30
IS300 01-05 XE10
GS300/Aristo 91-97 S140
GS300/Aristo 98-05 S160

Applicable Engines:

2JZ-GE, 2JZ-GE VVTi, 2JZ-GTE, 2JZ-GTE VVTi

Bore:

86.5mm

Primary Application:

Toyota Supra MKIV

Rod Length:

5.669" / 144mm

Rod Length Oversize:

0.079" / 2.0mm

Bore Oversize:

0.020" / 0.5mm

Stroke:

90mm (3.2L Stroker)

Compression Ratio:

8.9:1

Pin Size:

0.866" / 22mm

Included Ring Set:

CPT-3406PVD

Included Pin:

CA8662500250CD

Head cc:

45 cc

Dome cc:

-14.16 cc

Compression Height:

1.176" / 29.87mm

Piston Material:

2618

Wrist Pin Wall Thickness:

0.259"

Wrist Pin Dimensions:

.866" x 2.500" x.259"

Pin Material:

TP1 Tool Steel DLC

Notes:

The Compression Ratio is 9.172:1

Gasket Thickness:

0.051" / 1.3mm

fbt:

Real Street RS2000 Pistons 2000HP for 2JZ-GTE 90mm Stroker 144mm Rod 86.5mm +0.5mm Bore -14.16cc 8.9:1

MSRP: $3,304.44

Your Price: $2,950.39

(You save $354.05 )

CP Pistons
