Centric Premium Rotors are blank, 1-piece, direct replacement discs for your factory brake system. These “black” rotors feature a special anti-corrosion e-coating that gives them their distinctive look and name, and are manufactured under QS and ISO quality system standards. Centric Premium Rotors are particularly desirable in fleet or emergency vehicle applications when an upgrade to StopTech Sport rotors is not possible.

Like many StopTech 1-piece rotors, Centric Premium Rotors offer several key advantages over stock rotors, E-coating, Double Disc Ground, Machined Finishes, Symmetric Vane Castings and Mill Balancing are just some of the processes we use.

E-Coat Finish
Centric premium rotors utilize an electrocoating finish that provides long lasting corrosion protection. E-coating is a superior electro-statically applied finish designed to withstand 400 hours of salt water exposure without rusting. Finishes used by other manufacturers provide only minimal protection from the elements and are generally only effective for the shipping and storage portion of a rotor’s life. The addition of heat and moisture eliminates the effectiveness of many of those finishes resulting in immediate corrosion once installed in the vehicle.

Double Disc Ground Braking Surface
Nearly all Centric premium rotors feature a double disc ground, taper free finish. Double disc grinding ensures parallelism, eliminates run out and provides near perfect disc thickness variation (DTV). Double disc grinding leaves a non-directional finish on the friction surface area for more effective pad-rotor break in. This special finish also provides quieter and smoother stops.

Fully Machined Hats Centric
Premium rotors feature 100 percent fully machined finishes including rotor hats. This extra process provides better rotor balance and creates a cleaner, more finished looking component.

Symmetric Vane Casting
The profile of the rotor’s cooling vane affects its ability to dissipate heat. Ideally the vane should have the same thickness at the points where it connects to the inner and outer friction plates. This is accomplished with symmetric vane core castings that provide proper heat transfer and thermal efficiency. This thickness symmetry in the vane promotes the uniform transfer of heat from both friction plates into the cooling vanes. Competitors’ vanes are often asymmetrical, which can lead to uneven heat transfer and compromises in performance and cooling.

Application:

• 2005-2010 CHRYSLER 300 V6 2.7 Position: Rear Left Solid Rear Disc
• 2005-2010 CHRYSLER 300 V6 3.5 Position: Rear Left Solid Rear Disc
• 2006-2010 CHRYSLER 300 V6 3.5 Position: Rear Left RWD Solid Rear Disc
• 2010-2010 CHRYSLER 300 V6 2.7 Position: Rear Left RWD Solid Rear Disc
• 2011-2011 CHRYSLER 300 V6 3.6 Position: Rear Left
• 2012-2012 CHRYSLER 300 V6 3.6 Position: Rear Left RWD Solid Rear Disc
• 2013-2013 CHRYSLER 300 V6 3.6 Position: Rear Left RWD Solid Rr Disc
• 2014-2016 CHRYSLER 300 V6 3.6 Position: Rear Left RWD exc Police Package
• 2017-2017 CHRYSLER 300 V6 3.6 Position: Rear Left AWD 2 Piston Front Caliper
• 2009-2010 DODGE CHALLENGER SE V6 3.5 Position: Rear Left Solid Rear Disc
• 2011-2011 DODGE CHALLENGER SE V6 3.6 Position: Rear Left Rallye Package
• 2012-2016 DODGE CHALLENGER V6 3.6 Position: Rear Left Touring Brakes
